Shortening hook

Shortening hook

Steel shortening hook is not an end element. It is used to adjust the length of the chain of the chain sling. It is selected in accordance with the size of the chain and the carrying capacity of the sling leg. Characteristics: 4x safety margin for tearing (8th strength class), has a fixed eyelet. Using components of the 8th strength class produced by TOR Industries Company makes it possible to reduce the weight of the sling while maintaining the rated reliability parameters.

Characteristics

Rated load, t	Tear strength, t	Chain, mm	A, mm	B, mm	C, mm	Weight, kg
1,12	4,5	6	13,5	8,0	69,3	0,14
2,0	8,0	8	18,0	10,8	81,5	0,25
3,15	12,6	10	20,0	13,0	109,0	0,65
5,3	21,2	13	26,0	16,5	142,5	1,39
8,0	32,0	16	30,5	20,0	151,7	2,20
12,5	50,0	20	37,5	25,0	196,0	4,60
15,0	60,0	22	44,0	28,0	233,0	8,20
21,2	84,8	26	41,0	30,0	265,5	9,80
31,5	126,0	32	57,0	38,0	323,0	19,40
